The ALTIC Paint Fire Rated Wooden Door is a solid wood, 120-minute fire-resistant door designed for industrial, commercial, and institutional applications. Manufactured using premium hardwood and fire-resistant insulation, it ensures maximum safety while maintaining aesthetic appeal.
Key Features
-
🔥 120 Minutes Fire Resistance
-
🪵 Solid Hardwood Construction (Red Meranti)
-
🧱 Fire Insulation Core for Heat Protection
-
🔒 Heat-Activated Intumescent Fire & Smoke Seals
-
🎨 Durable Powder-Coated Surface Finish
-
🛠️ Pre-Reinforced for Hardware Fixing
-
📜 Certified as per IS 3614-2021 & BS 476 Part 22
Technical Specifications
| Specification | Details |
|---|---|
| Type | Fire Rated Wooden Door |
| Material | Solid Wood |
| Door Type | Fire Resistant Door |
| Thickness | 50 mm (+2 mm tolerance) |
| Frame Material | Red Meranti Hardwood (120 × 70 mm) |
| Infilling Material | Fire Resistant Insulation (20 mm) |
| Surface Finish | Powder Coated |
| Design | Plain |
| Color | Brown (Custom options available) |
| Size | Standard / Custom |
| Fire Rating | 120 Minutes (BS 476 Part 22 & IS 3614-2021) |
Construction Details
-
Door Frame: Hardwood Red Meranti (120 × 70 mm), with grooves fitted with intumescent fire seal strips (10 × 4 mm) on three sides.
-
Door Shutter: Minimum 50 mm thick, composed of:
-
75 × 44 mm internal hardwood timber frame
-
20 mm fire-resistant insulation core
-
12 mm non-combustible boards on both sides
-
3 mm commercial plywood cladding on both faces
-
-
Sealing: Fire & smoke intumescent seals on all three sides except the bottom
-
Hardware Provisions: Pre-reinforced for fitting locks, hinges, and accessories (hardware supplied separately)
Trade Information
| Details | Information |
|---|---|
| Minimum Order Quantity | 10 Square Meters |
| Supply Ability | 2500 Square Meters / Month |
| Delivery Time | 15 Days |
| Sample Available | No |
| Sample Policy | Free samples (buyer pays shipping & taxes) |
| Packaging | Corrugated Paper / Wooden Box |
| Main Export Markets | Asia, Europe, Middle East, Africa, Americas, Australia |
| Main Domestic Market | All India |
| Certifications | BS 476 Part 22 & IS 3614-2021 (Govt. Lab Tested) |
Applications
-
Commercial Buildings
-
Industrial Facilities & Warehouses
-
Hospitals & Healthcare Units
-
Educational Institutions
-
Hotels & Residential Complexes
FAQs
Q1: What is the thickness of the door?
A: 50 millimeters (±2 mm).
Q2: What color options are available?
A: Standard brown; custom colors available on request.
Q3: What surface finish is applied?
A: Powder-coated finish for durability and corrosion resistance.
Q4: Is the door made of solid wood?
A: Yes, it is made from high-quality Red Meranti hardwood.
Q5: What is the fire rating of the door?
A: 120 minutes, tested and certified as per BS 476 Part 22 & IS 3614-2021.
